Air Conditioners
Viessmann Vitoclima 200-S – Advanced Air-to-Air Heat Pump and Air Conditioner (2.7 kW, for rooms up to 39 m²)
The Viessmann Vitoclima 200-S is a modern and efficient air-to-air heat pump and air conditioner, designed to cool and heat indoor spaces with optimal energy efficiency. This 2.7 kW version is perfect for rooms up to 39 m². Utilizing the eco-friendly refrigerant R32, it ensures high performance (SEER up to 7.0, SCOP up to 4.0) while fully complying with the latest environmental regulations.
Comprehensive System for Maximum Comfort
The Vitoclima 200-S set includes a pre-charged outdoor unit, a sleek and modern indoor unit with a backlit electronic display, and a remote control for effortless operation.
Key Features and Benefits:
✔ Wide Operating Range – Reliable operation in cooling mode from -15°C to +43°C, and in heating mode from -15°C to +24°C
✔ Night Mode – Optimized temperature control for enhanced nighttime comfort
✔ Built-in WiFi – Full remote control via the EWPE Smart app for convenient climate management
✔ Anti-Frost Protection Mode – Maintains a stable indoor temperature of +8°C to prevent freezing
✔ Warm Start Technology – In heating mode, the fan delays activation to ensure immediate warm air circulation
✔ Turbo Mode – Enables rapid heating or cooling for instant comfort
✔ Electronic Louver Control – Adjustable horizontal and vertical airflow for uniform temperature distribution
✔ Additional Room Sensor – Integrated into the remote control for accurate climate adjustments
✔ Dehumidification Function – Reduces excess moisture, improving indoor air quality
With its high efficiency, advanced control features, and sleek design, the Viessmann Vitoclima 200-S (2.7 kW) delivers exceptional comfort, energy savings, and reliable year-round performance, making it ideal for rooms up to 39 m².
Viessmann Vitoclima 200-S – Advanced Air-to-Air Heat Pump and Air Conditioner (7.0 kW, for rooms up to 100 m²)
The Viessmann Vitoclima 200-S is a modern and highly efficient air-to-air heat pump and air conditioner, designed to cool and heat indoor spaces with optimal energy performance. This 7.0 kW version is perfect for rooms up to 100 m². Utilizing the eco-friendly refrigerant R32, it ensures high efficiency (SEER up to 7.0, SCOP up to 4.0) while fully complying with the latest environmental standards.
Comprehensive System for Maximum Comfort
The Vitoclima 200-S set includes a pre-charged outdoor unit, a sleek and modern indoor unit with a backlit electronic display, and a remote control for effortless operation.
Key Features and Benefits:
✔ Wide Operating Range – Reliable operation in cooling mode from -15°C to +43°C, and in heating mode from -15°C to +24°C
✔ Night Mode – Optimized temperature control for enhanced nighttime comfort
✔ Built-in WiFi – Full remote control via the EWPE Smart app for convenient climate management
✔ Anti-Frost Protection Mode – Maintains a stable indoor temperature of +8°C to prevent freezing
✔ Warm Start Technology – In heating mode, the fan delays activation to ensure immediate warm air circulation
✔ Turbo Mode – Enables rapid heating or cooling for instant comfort
✔ Electronic Louver Control – Adjustable horizontal and vertical airflow for uniform temperature distribution
✔ Additional Room Sensor – Integrated into the remote control for accurate climate adjustments
✔ Dehumidification Function – Reduces excess moisture, improving indoor air quality
With its high efficiency, advanced control features, and sleek design, the Viessmann Vitoclima 200-S (7.0 kW) delivers exceptional comfort, energy savings, and reliable year-round performance, making it ideal for rooms up to 100 m².
Viessmann Vitoclima 230-S Dynamic – High-Efficiency Air Conditioner with AI (2.7 kW, for rooms up to 39 m²)
The Viessmann Vitoclima 230-S Dynamic is a premium air conditioner that combines comfort, smart climate control, and low energy consumption, thanks to its innovative self-adaptive AI technology. It actively learns user habits and environmental conditions to optimize operation in any season.
The set includes a sleek indoor unit with a backlit display, a pre-charged outdoor unit, and a remote control.
Key Features and Benefits
✔ AI Self-Adaptive Technology – Automatically adjusts to room temperature, humidity, and usage habits, saving up to 10% energy
✔ Humidity Control – Maintains 40–80% humidity in cooling mode, 30–70% in dehumidification – great for drying clothes
✔ UVC Lamp – Kills up to 93% of bacteria, viruses, and mold; safely enclosed for home use
✔ Inverter Technology – Adjusts compressor speed for maximum efficiency and low noise
✔ Operating Range – Works from -25 °C (heating) to +50 °C (cooling)
✔ Ultra-Quiet – Just 19 dB(A) indoors and 40 dB(A) outdoors in night mode
Additional Functions
✔ WiFi Control – Full mobile app integration
✔ I Feel Function – Sensor in remote control ensures precise temperature adjustment
✔ Turbo Mode – Rapid cooling or heating
✔ Hot Start – Prevents cold air from blowing at heating startup
✔ Sleep Mode – Reduces noise and temperature gradually
✔ +8 °C Winter Mode – Prevents room freezing
✔ Eco-Friendly Refrigerant – Uses R32 for high efficiency and low emissions
Air Quality Enhancements
✔ PM2.5 Filter, Silver Ions & Ionizer – Eliminates bacteria, pollen, mold, dust, and odors
✔ Self-Cleaning System – 5 steps: condensation, cooling, defrosting, drying, and 55 °C sterilization
Energy Efficiency
✔ Rated A+++ (cooling), A++ (heating)
The Vitoclima 230-S Dynamic (2.7 kW) is a smart, efficient, and health-conscious solution for year-round comfort in rooms up to 39 m².
Viessmann Vitoclima 230-S Dynamic – AI Air Conditioner (3.5 kW, for rooms up to 50 m²)
Vitoclima 230-S Dynamic (3.5 kW) is a smart, energy-efficient air conditioner with built-in AI learning algorithms. It adapts to the user’s routine and room conditions, making it ideal for rooms up to 50 m².
Key Features and Benefits
✔ AI Adaptive Control – Learns and saves up to 10% energy
✔ Humidity Management – Maintains 40–80% in cooling, 30–70% in drying
✔ UVC Lamp – Eliminates up to 93% of bacteria and viruses
✔ Inverter Compressor – Efficient and quiet operation
✔ Operating Range – From -25 °C to +50 °C
✔ Ultra Quiet – Just 19 dB(A) indoors
Additional Features
✔ WiFi Control – Via mobile app
✔ “I Feel” Mode – Temperature sensor in remote control
✔ Turbo Mode – Rapid heating or cooling
✔ Hot Start – Avoids cold air blasts
✔ Sleep Mode – For peaceful night operation
✔ +8 °C Winter Mode – Prevents freezing
✔ Eco-Friendly R32 Refrigerant
Air Quality Enhancements
✔ PM2.5 Filter, Ionizer & Silver Ions – Purifies air from allergens, odors, dust
✔ Self-Cleaning Cycle – Condensation, cooling, defrost, drying, 55 °C sterilization
Energy Efficiency
✔ Energy Class: A+++ (cooling), A++ (heating)
Viessmann Vitoclima 230-S Dynamic – Smart Air Conditioner with AI (5.1 kW, for rooms up to 72 m²)
Vitoclima 230-S Dynamic (5.1 kW) is a high-performance smart air conditioner offering year-round comfort, low energy consumption, and AI-driven adaptability. Perfect for larger rooms up to 72 m², it adjusts to user behavior and ambient conditions automatically.
Key Features and Benefits
✔ AI Self-Adaptive Technology – Learns user habits, saves up to 10% energy
✔ Humidity Control – 40–80% (cooling), 30–70% (dehumidifying)
✔ UVC Lamp – Eliminates up to 93% of bacteria and viruses
✔ Inverter Compressor – Efficient and silent operation
✔ Operating Range – From -25 °C to +50 °C
✔ Ultra-Quiet Night Mode – Only 19 dB(A) indoors
Additional Functions
✔ WiFi Control – Via mobile app
✔ “I Feel” Mode – Remote sensor for precise climate control
✔ Turbo Mode – Fast heating or cooling
✔ Hot Start – Prevents cold air blasts
✔ Sleep Mode – Quiet night-time operation
✔ +8 °C Winter Mode – Prevents freezing in unused rooms
✔ R32 Refrigerant – Eco-friendly and high efficiency
Air Quality Enhancements
✔ PM2.5 Filter, Ionizer & Silver Ions – Removes dust, allergens, and odors
✔ Self-Cleaning Cycle – 5 steps: condensation, cooling, defrost, drying, sterilization at 55 °C
Energy Efficiency
✔ A+++ (cooling), A++ (heating)
Viessmann Vitoclima 230-S Dynamic – Smart Air Conditioner with AI (6.5 kW, for rooms up to 92 m²)
Vitoclima 230-S Dynamic (6.5 kW) is a powerful, intelligent air conditioner offering year-round comfort, clean air, and energy savings. Its AI-based control system automatically learns user behavior and room conditions – ideal for spaces up to 92 m².
Key Features and Benefits
✔ AI Self-Learning – Optimizes performance and reduces energy use by up to 10%
✔ Humidity Control – Keeps 40–80% in cooling, 30–70% in drying mode
✔ UVC Lamp – Destroys up to 93% of harmful microbes
✔ Inverter Compressor – Efficient, quiet and stable operation
✔ Operating Range – -25 °C to +50 °C
✔ Super Quiet – Just 19 dB(A) indoors during night mode
Additional Functions
✔ WiFi Control – Manage easily via mobile app
✔ “I Feel” Mode – Accurate temperature via remote sensor
✔ Turbo Mode – Rapid heating or cooling
✔ Hot Start – Prevents cold air blasts
✔ Sleep Mode – Ultra-quiet night operation
✔ +8 °C Winter Mode – Prevents freezing indoors
✔ Eco-Friendly R32 Refrigerant
Enhanced Air Quality
✔ PM2.5 Filter, Ionizer & Silver Ions – Removes allergens, odors, and pollutants
✔ Self-Cleaning – 5-phase: condensation, cooling, defrost, drying, sterilization at 55 °C
Energy Efficiency
✔ Rated: A+++ (cooling), A++ (heating)
AIR CONDITIONER VIESSMANN VITOCLIMA 300-S/HE CF3035M1 - CEILING CASSETTE INDOOR UNIT 3.5 KW
Viessmann Vitoclima 300-S/HE CF3035M1 is a ceiling cassette indoor unit for the Vitoclima 300-S Multi-split system. The unit provides a nominal cooling capacity of 3.5 kW and a nominal heating capacity of 4.0 kW.
Main features and benefits
✔ Cooling capacity 3.5 kW – nominal capacity in cooling mode
✔ Heating capacity 4.0 kW – nominal capacity in heating mode
✔ Power supply 220–240 V / 50 Hz – single-phase electrical connection
✔ Power cable 4 × 1.0 mm² – for the electrical connection of the indoor unit
✔ Fan power 30 W – nominal fan power
✔ Fan current 0.1 A – nominal fan current
✔ Airflow 650 / 560 / 520 / 450 m³/h – airflow at different operating settings
✔ Sound pressure level 44 / 41 / 38 / 34 dB(A) – noise level at different operating settings
✔ Sound power level 55 / 52 / 49 / 45 dB(A) – sound power level at different operating settings
✔ Temperature setting range 16–30 °C – available temperature setting range
✔ Dehumidification capacity 1.4 l/h – moisture removal performance
✔ Liquid pipe connection 6.35 mm / ¼" – refrigerant liquid line connection
✔ Gas pipe connection 9.52 mm / ⅜" – refrigerant gas line connection
✔ Net / gross weight 20.0 / 24.0 kg – indoor unit weight
✔ Unit dimensions 596 × 596 × 240 mm – length × width × height
✔ Panel net / gross weight 3.5 / 5.0 kg – decorative panel weight
✔ Panel dimensions 670 × 670 × 50 mm – length × width × height
✔ 24 h timer – allows the unit's switch-on and switch-off times to be set
✔ +8 °C function – maintains a room temperature of +8 °C in heating mode during winter
Vitoclima 300-S/HE CF3035M1 is designed for use with the Vitoclima 300-S Multi-split system.
AIR CONDITIONER VIESSMANN VITOCLIMA 300-S/HE O2F3050M3 ODU - MULTI-SPLIT OUTDOOR UNIT 5.3 KW, UP TO 2 INDOOR UNITS
Viessmann Vitoclima 300-S/HE O2F3050M3 ODU is a Multi-split outdoor unit that allows connection of up to 2 Vitoclima 300-S indoor units. The unit provides a nominal cooling capacity of 5.3 kW and a nominal heating capacity of 5.65 kW and uses R32 refrigerant.
Main features and benefits
✔ Cooling capacity 5.3 kW – nominal capacity in cooling mode
✔ Heating capacity 5.65 kW – nominal capacity in heating mode
✔ Up to 2 indoor units – allows connection of 1 to 2 Vitoclima 300-S indoor units
✔ Cooling capacity range 2.14 / 5.30 / 5.80 kW – minimum / nominal / maximum capacity
✔ Heating capacity range 2.58 / 5.65 / 6.50 kW – minimum / nominal / maximum capacity
✔ Power supply 220–240 V / 50 Hz – single-phase electrical connection
✔ Power cable 3 × 1.5 mm² – for the electrical connection of the outdoor unit
✔ Power consumption 1.48 / 1.25 kW – nominal power consumption in cooling / heating mode
✔ EER 3.58 – energy efficiency ratio in cooling mode
✔ COP 4.53 – energy efficiency ratio in heating mode
✔ SEER 7.20 – seasonal energy efficiency ratio in cooling mode
✔ Energy efficiency class A++ / A+ – cooling / heating mode
✔ Nominal current 6.56 / 5.55 A – cooling / heating mode
✔ Airflow 2300 m³/h – outdoor unit fan airflow
✔ Cooling operating range -15 to +43 °C – outdoor temperature range in cooling mode
✔ Heating operating range -22 to +24 °C – outdoor temperature range in heating mode
✔ Sound power level 64 dB(A) – outdoor unit sound power level
✔ Refrigerant R32 / 0.9 kg – refrigerant type and quantity
✔ Maximum piping length without additional refrigerant 10 m – refrigerant piping length without additional refrigerant
✔ Additional refrigerant quantity 20 g/m – additional refrigerant quantity
✔ Liquid pipe connections 2 × 6.35 mm / 2 × ¼" – liquid line connections
✔ Gas pipe connections 2 × 9.52 mm / 2 × ⅜" – gas line connections
✔ Total piping length 40 m – maximum total installation length
✔ Distance to the last indoor unit 20 m – maximum piping length between the outdoor unit and the last indoor unit
✔ Height difference 15 m – maximum height difference between indoor units
✔ Net / gross weight 32.0 / 34.5 kg – outdoor unit weight
✔ Unit dimensions 745 × 300 × 550 mm – width × depth × height
Vitoclima 300-S/HE O2F3050M3 ODU is designed for the Vitoclima 300-S Multi-split system with up to 2 connectable indoor units.
AIR CONDITIONER VIESSMANN VITOCLIMA 300-S/HE O4F3080M3 ODU - MULTI-SPLIT OUTDOOR UNIT 8.2 KW, UP TO 4 INDOOR UNITS
Viessmann Vitoclima 300-S/HE O4F3080M3 ODU is a Multi-split outdoor unit that allows connection of up to 4 Vitoclima 300-S indoor units. The unit provides a nominal cooling capacity of 8.2 kW and a nominal heating capacity of 9.5 kW and uses R32 refrigerant.
Main features and benefits
✔ Cooling capacity 8.2 kW – nominal capacity in cooling mode
✔ Heating capacity 9.5 kW – nominal capacity in heating mode
✔ Up to 4 indoor units – allows connection of 2 to 4 Vitoclima 300-S indoor units
✔ Cooling capacity range 2.30 / 8.20 / 11.00 kW – minimum / nominal / maximum capacity
✔ Heating capacity range 3.65 / 9.50 / 10.25 kW – minimum / nominal / maximum capacity
✔ Power supply 220–240 V / 50 Hz – single-phase electrical connection
✔ Power cable 3 × 2.5 mm² – for the electrical connection of the outdoor unit
✔ Power consumption 2.10 / 2.20 kW – nominal power consumption in cooling / heating mode
✔ EER 3.90 – energy efficiency ratio in cooling mode
✔ COP 4.32 – energy efficiency ratio in heating mode
✔ SEER 7.20 – seasonal energy efficiency ratio in cooling mode
✔ Energy efficiency class A++ / A+ – cooling / heating mode
✔ Nominal current 9.32 / 9.77 A – cooling / heating mode
✔ Airflow 3800 m³/h – outdoor unit fan airflow
✔ Cooling operating range -15 to +43 °C – outdoor temperature range in cooling mode
✔ Heating operating range -22 to +24 °C – outdoor temperature range in heating mode
✔ Sound power level 68 dB(A) – outdoor unit sound power level
✔ Refrigerant R32 / 1.8 kg – refrigerant type and quantity
✔ Maximum piping length without additional refrigerant 40 m – refrigerant piping length without additional refrigerant
✔ Additional refrigerant quantity 20 g/m – additional refrigerant quantity
✔ Liquid pipe connections 4 × 6.35 mm / 4 × ¼" – liquid line connections
✔ Gas pipe connections 4 × 9.52 mm / 4 × ⅜" – gas line connections
✔ Total piping length 70 m – maximum total installation length
✔ Distance to the last indoor unit 20 m – maximum piping length between the outdoor unit and the last indoor unit
✔ Height difference 15 m – maximum height difference between indoor units
✔ Net / gross weight 51.0 / 55.5 kg – outdoor unit weight
✔ Unit dimensions 889 × 340 × 654 mm – width × depth × height
Vitoclima 300-S/HE O4F3080M3 ODU is designed for the Vitoclima 300-S Multi-split system with up to 4 connectable indoor units.
AIR CONDITIONER VIESSMANN VITOCLIMA 300-S/HE O4F3100M3 ODU - MULTI-SPLIT OUTDOOR UNIT 10.6 KW, UP TO 4 INDOOR UNITS
Viessmann Vitoclima 300-S/HE O4F3100M3 ODU is a Multi-split outdoor unit that allows connection of up to 4 Vitoclima 300-S indoor units. The unit provides a nominal cooling capacity of 10.6 kW and a nominal heating capacity of 12.0 kW and uses R32 refrigerant.
Main features and benefits
✔ Cooling capacity 10.6 kW – nominal capacity in cooling mode
✔ Heating capacity 12.0 kW – nominal capacity in heating mode
✔ Up to 4 indoor units – allows connection of 2 to 4 Vitoclima 300-S indoor units
✔ Cooling capacity range 2.60 / 10.60 / 12.00 kW – minimum / nominal / maximum capacity
✔ Heating capacity range 3.00 / 12.00 / 14.00 kW – minimum / nominal / maximum capacity
✔ Power supply 220–240 V / 50 Hz – single-phase electrical connection
✔ Power cable 3 × 4.0 mm² – for the electrical connection of the outdoor unit
✔ Power consumption 3.00 / 3.04 kW – nominal power consumption in cooling / heating mode
✔ EER 3.53 – energy efficiency ratio in cooling mode
✔ COP 3.95 – energy efficiency ratio in heating mode
✔ SEER 7.20 – seasonal energy efficiency ratio in cooling mode
✔ Energy efficiency class A++ / A+ – cooling / heating mode
✔ Nominal current 13.31 / 13.49 A – cooling / heating mode
✔ Airflow 5800 m³/h – outdoor unit fan airflow
✔ Cooling operating range -15 to +43 °C – outdoor temperature range in cooling mode
✔ Heating operating range -22 to +24 °C – outdoor temperature range in heating mode
✔ Sound power level 70 / 70 dB(A) – cooling / heating mode
✔ Refrigerant R32 / 2.40 kg – refrigerant type and quantity
✔ Maximum piping length without additional refrigerant 40 m – refrigerant piping length without additional refrigerant
✔ Additional refrigerant quantity 20 g/m – additional refrigerant quantity
✔ Liquid pipe connections 4 × 6.35 mm / 4 × ¼" – liquid line connections
✔ Gas pipe connections 4 × 9.52 mm / 4 × ⅜" – gas line connections
✔ Total piping length 80 m – maximum total installation length
✔ Distance to the last indoor unit 25 m – maximum piping length between the outdoor unit and the last indoor unit
✔ Height difference 25 m – maximum height difference between indoor units
✔ Net / gross weight 72.0 / 79.0 kg – outdoor unit weight
✔ Unit dimensions 1020 × 427 × 826 mm – width × depth × height
Vitoclima 300-S/HE O4F3100M3 ODU is designed for the Vitoclima 300-S Multi-split system with up to 4 connectable indoor units.
AIR CONDITIONER VIESSMANN VITOCLIMA 300-S/HE O5F3120M3 ODU - MULTI-SPLIT OUTDOOR UNIT 12.1 KW, UP TO 5 INDOOR UNITS
Viessmann Vitoclima 300-S/HE O5F3120M3 ODU is a Multi-split outdoor unit that allows connection of up to 5 Vitoclima 300-S indoor units. The unit provides a nominal cooling capacity of 12.1 kW and a nominal heating capacity of 13.0 kW and uses R32 refrigerant.
Main features and benefits
✔ Cooling capacity 12.1 kW – nominal capacity in cooling mode
✔ Heating capacity 13.0 kW – nominal capacity in heating mode
✔ Up to 5 indoor units – allows connection of 2 to 5 Vitoclima 300-S indoor units
✔ Cooling capacity range 2.60 / 12.10 / 15.20 kW – minimum / nominal / maximum capacity
✔ Heating capacity range 3.00 / 13.00 / 15.50 kW – minimum / nominal / maximum capacity
✔ Power supply 220–240 V / 50 Hz – single-phase electrical connection
✔ Power cable 3 × 4.0 mm² – for the electrical connection of the outdoor unit
✔ Power consumption 3.40 / 3.19 kW – nominal power consumption in cooling / heating mode
✔ EER 3.56 – energy efficiency ratio in cooling mode
✔ COP 4.08 – energy efficiency ratio in heating mode
✔ SEER 7.20 – seasonal energy efficiency ratio in cooling mode
✔ Energy efficiency class A++ / A+ – cooling / heating mode
✔ Nominal current 15.08 / 14.15 A – cooling / heating mode
✔ Airflow 5800 m³/h – outdoor unit fan airflow
✔ Cooling operating range -15 to +43 °C – outdoor temperature range in cooling mode
✔ Heating operating range -22 to +24 °C – outdoor temperature range in heating mode
✔ Sound power level 72 / 74 dB(A) – cooling / heating mode
✔ Refrigerant R32 / 2.40 kg – refrigerant type and quantity
✔ Maximum piping length without additional refrigerant 50 m – refrigerant piping length without additional refrigerant
✔ Additional refrigerant quantity 20 g/m – additional refrigerant quantity
✔ Liquid pipe connections 5 × 6.35 mm / 5 × ¼" – liquid line connections
✔ Gas pipe connections 5 × 9.52 mm / 5 × ⅜" – gas line connections
✔ Total piping length 100 m – maximum total installation length
✔ Distance to the last indoor unit 25 m – maximum piping length between the outdoor unit and the last indoor unit
✔ Height difference 25 m – maximum height difference between indoor units
✔ Net / gross weight 73.0 / 80.0 kg – outdoor unit weight
✔ Unit dimensions 1020 × 427 × 826 mm – width × depth × height
Vitoclima 300-S/HE O5F3120M3 ODU is designed for the Vitoclima 300-S Multi-split system with up to 5 connectable indoor units.
