Industrial heat pumps
Viessmann Vitocal 200-A PRO – Commercial Air-to-Water Heat Pump (32 kW, Monoblock)
The Viessmann Vitocal 200-A PRO (32 kW) is a high-performance monoblock air-to-water heat pump engineered for commercial applications and larger residential buildings. It delivers efficient heating and cooling with robust performance, even in low outdoor temperatures down to -20 °C.
Using R407C refrigerant, the system supports flow temperatures up to 60 °C and is suitable for retrofit and new-build installations. The durable aluminium and powder-coated steel housing with sound insulation makes it ideal for sensitive urban or commercial environments.
Key Features and Benefits
✔ Nominal Heating Capacity: 32 kW (A7/W35)
✔ Operating Temperature Range: Down to –20 °C ambient
✔ Maximum Flow Temperature: Up to 60 °C
✔ Refrigerant: R407C
✔ Heating and Cooling: Ideal for multi-family buildings, hotels, offices
✔ Hydraulic Module Integration: For direct system connection
✔ Modular System Design: Can be cascaded up to 8 units (up to 256 kW)
✔ Casing: Corrosion-resistant aluminium/stainless steel, powder-coated
✔ Advanced Control: Vitotronic 200 with touch display and Modbus/BACnet interface
✔ Low Noise: Optimized acoustic design for noise-sensitive areas
Vitocal 200-A PRO (32 kW) offers reliable, scalable, and efficient heating and cooling, purpose-built for professional and commercial use.
Viessmann Vitocal 200-A PRO – Commercial Air-to-Water Heat Pump (64 kW, Monoblock)
The Viessmann Vitocal 200-A PRO (64 kW) is a commercial-grade monoblock air-to-water heat pump, designed for multi-residential buildings, offices, schools, and hotels. It provides high-capacity heating and cooling down to –20 °C outdoor temperature, with flow temperatures of up to 60 °C.
Operating on R407C refrigerant, this system is designed for durability, scalability, and quiet operation. It can be installed as a standalone unit or in a cascade system of up to 8 units, delivering total capacity up to 512 kW.
Key Features and Benefits
✔ Nominal Heating Capacity: 64 kW (A7/W35)
✔ Flow Temperature: Up to 60 °C
✔ Operating Range: Down to –20 °C outdoor temperature
✔ Refrigerant: R407C
✔ Heating and Cooling: Ideal for large commercial environments
✔ Modular Design: Cascade up to 8 units (up to 512 kW)
✔ Hydraulic Module: Built-in for easy installation
✔ Corrosion-Resistant Housing: Aluminium and powder-coated steel
✔ Advanced Control System: Vitotronic 200 with Modbus/BACnet support
✔ Low Noise Operation: Engineered for noise-sensitive installations
Vitocal 200-A PRO (64 kW) delivers scalable and efficient climate control, optimized for demanding commercial applications.
Viessmann Vitocal 200-A PRO – Commercial Air-to-Water Heat Pump (128 kW, Monoblock)
The Viessmann Vitocal 200-A PRO (128 kW) is a high-capacity air-to-water heat pump designed for large commercial and multi-residential buildings, offering high-output heating and cooling in a compact and scalable monoblock unit. It’s ideal for district heating, hotels, office buildings, or industrial applications.
Operating on R407C refrigerant, the unit supports flow temperatures up to 60 °C and operates reliably in outdoor temperatures as low as –20 °C. The modular concept allows this unit to be combined in cascades up to 8 units, reaching a total system capacity of over 1 MW.
Key Features and Benefits
✔ Nominal Heating Output: 128 kW (A7/W35)
✔ Operating Range: Down to –20 °C ambient
✔ Max Flow Temperature: Up to 60 °C
✔ Refrigerant: R407C
✔ Use Case: Large commercial buildings, hotels, industrial facilities
✔ Hydraulic Module: Built-in for simplified installation
✔ Modular Installation: Cascade up to 8 units (up to 1024 kW total capacity)
✔ Low Sound Emission: Quiet operation for urban environments
✔ Corrosion-Resistant Housing: Aluminium/stainless steel, powder-coated
✔ Control System: Vitotronic 200 with Modbus/BACnet interface
✔ Indoor/Outdoor Use: Compact, flexible positioning
Vitocal 200-A PRO (128 kW) is a robust and scalable solution for large-scale heating and cooling needs, combining Viessmann quality, energy efficiency, and commercial flexibility.
